Ankyrin 3 Antibody (2A8)
Novus Biologicals, part of Bio-Techne | Catalog # NBP3-05528
![Western Blot: Ankyrin 3 Antibody [NBP3-05528]](https://resources.bio-techne.com/images/products/Ankyrin-3-Antibody-Western-Blot-NBP3-05528-img0002.jpg "Western Blot: Ankyrin 3 Antibody [NBP3-05528]")
Conjugate
Catalog #
Key Product Details
Species Reactivity
Human, Rat
Applications
Immunocytochemistry/ Immunofluorescence, Immunohistochemistry, Western Blot
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG1 Clone # 2A8
Concentration
1 mg/ml
Product Specifications
Immunogen
The C-terminal 398 amino acids of human Ankyrin 3 expressed in and purified from E. coli.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG1
Scientific Data Images for Ankyrin 3 Antibody (2A8)
Western Blot: Ankyrin 3 Antibody [NBP3-05528]
Western Blot: Ankyrin 3 Antibody [NBP3-05528] - Western blot analysis of different tissue and cell lysates using Ankyrin 3 Antibody, at a at a dilution of of 1:2,000 in green: [1] protein standard (red), [2] NIH-3T3, [3] C6, [4] HEK293, [5] HeLa, [6] SH-SY5Y cells, [7] rat brain, and [8] mouse brain lysates. Bands at ~190kDa represent ankyrin 3 splice variants, higher molecular weight bands at 270kDa and 480kDa can be seen on longer exposure. Lower molecular weight bands are likely proteolytic fragments.![Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]](https://resources.bio-techne.com/images/products/Ankyrin-3-Antibody-Immunocytochemistry-Immunofluorescence-NBP3-05528-img0003.jpg "Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]")
Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]
Immunocytochemistry/Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528] - Immunofluorescent analysis of cortex section of rat brain stained with Ankyrin 3 Antibody at a at a dilution of of 1:2,000 in green and costained with rabbit polyclonal antibody to NF-L at a at a dilution of of 1:5,000 in red. The blue is Hoechst staining of nuclear DNA. Following transcardial perfusion of rat with 4% paraformaldehyde, brain was post fixed for 24 hours, cut to 45uM, and free-floating sections were stained with above antibodies. The Ankyrin 3 Antibody stains the axonal initial segments, while the NF-L antibody labels dendrites and axons of neuronal cells.![Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]](https://resources.bio-techne.com/images/products/Ankyrin-3-Antibody-Immunocytochemistry-Immunofluorescence-NBP3-05528-img0001.jpg "Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]")
Immunocytochemistry/ Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528]
Immunocytochemistry/Immunofluorescence: Ankyrin 3 Antibody [NBP3-05528] - Immunofluorescent analysis of cortex section of rat brain stained with Ankyrin 3 Antibody at a at a dilution of of 1:2,000 in green and costained with rabbit polyclonal antibody to NF-L at a at a dilution of of 1:5,000 in red. The blue is Hoechst staining of nuclear DNA. Following transcardial perfusion of rat with 4% paraformaldehyde, brain was post fixed for 24 hours, cut to 45uM, and free-floating sections were stained with above antibodies. The Ankyrin 3 Antibody stains the axonal initial segments, while the NF-L antibody labels dendrites and axons of neuronal cells.Applications for Ankyrin 3 Antibody (2A8)
Application
Recommended Usage
Immunocytochemistry/ Immunofluorescence
1:1000
Immunohistochemistry
1:1000
Western Blot
1:1000-1:2000
Formulation, Preparation, and Storage
Purification
Immunogen affinity purified
Formulation
50% PBS, 50% glycerol
Preservative
0.035% Sodium Azide
Concentration
1 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C short term. Store at -20C long term. Avoid freeze-thaw cycles.
Background: Ankyrin 3
Alternate Names
ankyrin G, Ankyrin G119, ankyrin-3, ankyrin-G, Node Of Ranvier
Gene Symbol
ANK3
Additional Ankyrin 3 Products
Product Documents for Ankyrin 3 Antibody (2A8)
Product Specific Notices for Ankyrin 3 Antibody (2A8)
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
