CD45 Antibody (30-F11) - BSA Free

Novus Biologicals, part of Bio-Techne | Catalog # NB100-77417

Novus Biologicals, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
NB100-77417
NB100-77417SS
Print Quote
Bulk Order
100% Guarantee

Key Product Details

Species Reactivity

Validated:

Human, Mouse, Rat

Cited:

Human, Mouse, Rat

Applications

Validated:

CyTOF-ready, Flow Cytometry, Functional, Immunocytochemistry/ Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Frozen, Immunohistochemistry-Paraffin, Immunoprecipitation, In vitro assay, In vivo assay, Western Blot

Cited:

Flow Cytometry, Functional Assay, IF/IHC, Immunocytochemistry/ Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Frozen, Immunohistochemistry-Paraffin, In vitro assay, In vivo assay, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Rat IgG2b Kappa Clone # 30-F11

Format

BSA Free

Concentration

1.0 mg/ml

View all CD45 Antibodies »

Product Specifications

Immunogen

This CD45 Antibody (30-F11) was prepared from Mouse thymus or spleen.

Reactivity Notes

Use in Human reported in scientific literature (PMID:34494385).

Localization

Transmembrane Protein with Extracellular, Helical and Cytoplasmic Domains

Specificity

Recognizes all CD45 isoforms as well as the known mouse CD45 alloantigens (CD45-1/Ly 5a and CD45-2/Ly 5b)

Clonality

Monoclonal

Host

Rat

Isotype

IgG2b Kappa

Theoretical MW

145 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for CD45 Antibody (30-F11) - BSA Free

Flow Cytometry: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Flow Cytometry: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Flow Cytometry: CD45 Antibody (30-F11) [NB100-77417] - Analysis of CD45 (30F11) in freshly isolated mouse (Balb C) splenocytes (1x10^6) were stained with [NB100-77417] at 1:1000 dilution and detected with FITC conjugated donkey anti-rat IgG secondary (orange). Shown with rat IgG isotype control (blue).
Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) [NB100-77417] - Analysis of FFPE section of mouse spleen using rat monoclonal CD45 antibody (30-F11) [NB100-77417] at 1:50 dilution. The antibody generated an expected membrane staining in the red and white pulp spleenocytes of the tested spleen section.
Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) - BSA Free [NB100-77417]

Immunohistochemistry-Paraffin: CD45 Antibody (30-F11) [NB100-77417] - Mouse glomeruli stained with CD45 antibody. 4% formaldehyde fixed paraffin sections. EDTA was used for antigen retrieval. IHC-P image submitted by a verified customer review.
View 6 more images

Applications for CD45 Antibody (30-F11) - BSA Free

Application
Recommended Usage

Flow Cytometry

1:10-1:1000

Functional

reported in scientific literature (PMID 7743522)

Immunocytochemistry/ Immunofluorescence

1:10-1:500

Immunohistochemistry

1:10-1:500

Immunohistochemistry-Frozen

1:10-1:500

Immunohistochemistry-Paraffin

1:10-1:500

Immunoprecipitation

1:10-1:500

In vitro assay

reported in scientific literature (PMID 1974916)

In vivo assay

reported in multiple pieces of scientific literature

Western Blot

1:100-1:2000
Application Notes
Each lot of this CD45 antibody is quality control tested by immunofluorescent staining with flow cytometric analysis. IF data from customer review. For immunofluorescent staining, the suggested use of this reagent is: 0.25 microgram per one million cells in 100 microliter volume. It is recommended that the reagent be titrated for optimal performance for each application. This antibody is CyTOF ready. NB100-77417 may also be used for IHC with acetone-fixed frozen sections, zinc-fixed paraffin-embedded sections.
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Reviewed Applications

Read 5 reviews rated 4.8 using NB100-77417 in the following applications:

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.02% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: CD45

CD45, also known as leukocyte common antigen (LCA), T200, or Ly5, is a member C of the class 1 receptor-like protein tyrosine phosphatase (PTPRC) family (1, 2). It is a transmembrane glycoprotein which, due to alternative splicing, has a multiple isoforms with a theoretical molecular weight ranging from 180 - 220 kDa (1, 3-5). Human CD45 is synthesized as a 1281 amino acid sequence consisting of an alternatively spliced extracellular receptor-like region, a cysteine-rich domain, fibronectin-like III repeats, a transmembrane segment, and a cytoplasmic region with tandem protein tyrosine phosphatase (PTP) domains: the membrane proximal domain (D1) and the membrane distal domain (D2) (3, 5). CD45 is expressed on all nucleated hematopoietic cells and their precursors, except mature red blood cells, and is one of the most abundantly-expressed cell-surface glycoproteins, comprising approximately 10% of surface proteins in lymphocytes (3). Functionally, CD45 is essential for development and activation of T-cells and B-cells (1-5). More specifically, CD45 positively regulates antigen receptor signaling and Src-family member kinase activity (1, 3). There are many ways to regulate CD45 phosphatase activity including ligand binding, dimerization, protein interactions, cellular localization, and covalent modifications (3, 6). Ligands for CD45 include pUL11, a transmembrane protein of the cytomegalovirus RL11 (CMV RL11) family, and placental protein 14 (PP14), both of which exclusively bind CD45, and various lectins including CD22, galectin-1, galectin-3, macrophage mannose receptor (MR), and macrophage galactose-type lectin (MGL) (6).

Given its role in immune cell development and activation, CD45 has also been linked to a variety of diseases. The importance of CD45 in immunity has been revealed in human and mouse studies where CD45-deficiency leads to a severe-combined immunodeficiency (SCID) phenotype (2, 3, 6). A CD45-knockout mice study revealed inhibited thymocyte production and poor B-cell response, whereas CD45 activation in mice causes lymphoproliferation and autoantibody production (3). CD45 variants have been associated with altered immune function and autoimmune disorders including multiple sclerosis, systemic lupus erythematosus (SLE), and rheumatoid arthritis (6). Furthermore, altered CD45 expression has been implicated in oncological conditions including chronic lymphatic leukemia, acute lymphatic leukemia, Hodgkin lymphoma, multiple myeloma, and diffuse large B-cell lymphoma (6). Considering its role in autoimmune disorders, immunodeficiency and cancer, CD45 is an ideal therapeutic target (3, 6). The main approaches to control CD45 function is through either selective inhibitors or anti-CD45 antibodies (3).

Alternative names for CD45 includes B220, CD antigen: CD45, CD45 antigen, CD45R, EC 3.1.3.48, GP180, LCA, Leukocyte common antigen, LY5, protein tyrosine phosphatase receptor type c polypeptide, PTPRC, receptor-type tyrosine-protein phosphatase C, T200 Glycoprotein, and T200.

References

1. Trowbridge, I. S., & Thomas, M. L. (1994). CD45: an emerging role as a protein tyrosine phosphatase required for lymphocyte activation and development. Annual review of immunology. https://doi.org/10.1146/annurev.iy.12.040194.000505

2. Andersen, J. N., Jansen, P. G., Echwald, S. M., Mortensen, O. H., Fukada, T., Del Vecchio, R., Tonks, N. K., & Moller, N. P. (2004). A genomic perspective on protein tyrosine phosphatases: gene structure, pseudogenes, and genetic disease linkage. FASEB journal : official publication of the Federation of American Societies for Experimental Biology.

3. Hermiston, M. L., Xu, Z., & Weiss, A. (2003). CD45: a critical regulator of signaling thresholds in immune cells. Annual review of immunology. https://doi.org/10.1146/annurev.immunol.21.120601.140946

4. Tonks, N. K., Diltz, C. D., & Fischer, E. H. (1990). CD45, an integral membrane protein tyrosine phosphatase. Characterization of enzyme activity. The Journal of biological chemistry.

5. Nam, H. J., Poy, F., Saito, H., & Frederick, C. A. (2005). Structural basis for the function and regulation of the receptor protein tyrosine phosphatase CD45. The Journal of experimental medicine. https://doi.org/10.1084/jem.20041890

6. Rheinlander, A., Schraven, B., & Bommhardt, U. (2018). CD45 in human physiology and clinical medicine. Immunology letters. https://doi.org/10.1016/j.imlet.2018.01.009

Long Name

Cluster of Differentiation 45

Alternate Names

CD45, LCA, PTPRC, T200 Glycoprotein

Entrez Gene IDs

19264 (Mouse)

Gene Symbol

PTPRC

UniProt

P06800 (Mouse)

Additional CD45 Products

Product Documents for CD45 Antibody (30-F11) - BSA Free

Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Download SDS

Product Specific Notices for CD45 Antibody (30-F11) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
