F4/80 Antibody (4J7L6)

Novus Biologicals, part of Bio-Techne | Catalog # NBP3-33457

Novus Biologicals, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
NBP3-33457-100ul
NBP3-33457-20ul
Print Quote
Bulk Order
100% Guarantee

Key Product Details

Species Reactivity

Mouse

Applications

ELISA, Immunohistochemistry, Immunohistochemistry-Paraffin

Label

Unconjugated

Antibody Source

Monoclonal Rabbit IgG Clone # 4J7L6

Concentration

Please see the vial label for concentration. If unlisted please contact technical services.

View all F4/80 Antibodies »

Product Specifications

Immunogen

Recombinant fusion protein containing a sequence corresponding to amino acids 367-645 of mouse F4/80(NP_034260.1).

Sequence:
KRILFKCKEDLILQSEQIQQCQAVQGRDLGYASFCTLVNATFTILDNTCENKSAPVSLQSAATSVSLVLEQATTWFELSKEETSTLGTILLETVESTMLAALLIPSGNASQMIQTEYLDIESKVINEECKENESINLAARGDKMNVGCFIIKESVSTGAPGVAFVSFAHMESVLNERFFEDGQSFRKLRMNSRVVGGTVTGEKKEDFSKPIIYTLQHIQPKQKSERPICVSWNTDVEDGRWTPSGCEIVEASETHTVCSCNRMANLAIIMASGELTMEF

Clonality

Monoclonal

Host

Rabbit

Isotype

IgG

Scientific Data Images for F4/80 Antibody (4J7L6)

F4/80 Antibody (4J7L6)

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] -

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] - Immunohistochemistry analysis of paraffin-embedded Mouse spleen using F4/80 Rabbit mAb at dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.
F4/80 Antibody (4J7L6)

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] -

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] - Immunohistochemistry analysis of paraffin-embedded Mouse colon using F4/80 Rabbit mAb at dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.
F4/80 Antibody (4J7L6)

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] -

Immunohistochemistry: F4/80 Antibody (4J7L6) [NBP3-33457] - Immunohistochemistry analysis of paraffin-embedded Mouse liver using F4/80 Rabbit mAb at dilution of 1:200 (40x lens). High pressure antigen retrieval performed with 0.01M Citrate Bufferr (pH 6.0) prior to IHC staining.

Applications for F4/80 Antibody (4J7L6)

Application
Recommended Usage

ELISA

Recommended starting concentration is 1 ug/mL

Immunohistochemistry-Paraffin

1:50 - 1:200

Formulation, Preparation, and Storage

Purification

Affinity purified

Formulation

PBS (pH 7.3), 50% glycerol, 0.05% BSA

Preservative

0.05% Proclin 300

Concentration

Please see the vial label for concentration. If unlisted please contact technical services.

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at -20C. Avoid freeze-thaw cycles.

Background: F4/80

F4/80 antigen is a cell surface glycoprotein that is the murine homolog of human EGF-like module-containing mucin-like hormone receptor-like 1 (EMR1) (1,2). Specifically, F4/80 (EMR1) is one of five members belonging to the adhesion G-coupled receptor (ADGRE) subfamily, also known as the epidermal growth factor seven transmembrane (EGF-TM7) receptors (1,2). F4/80 is expressed by the myeloid lineage including in eosinophils, monocytes, macrophages, and myeloid dendritic cells (1,2). The molecular structure of F4/80 contains an EGF-like extracellular domain and a seven transmembrane motif, with a theoretical molecular weight of 160 kDa (1).

Depending on factors such as differentiation, activation, and location, the level of F4/80 expression can vary between cell-types (1,2). For example, peritoneal macrophages are subdivided based on morphology and expression with large peritoneal macrophages having high levels of F4/80 and small peritoneal macrophages having low F4/80 expression (1). Furthermore, splenic macrophages are classified based on location (red pulp, marginal zone, and white pulp) and F4/80 expression level varies within these populations as well; the red pulp macrophages have high levels of F4/80 and CD68 by comparison (1). Originally, the F4/80 monoclonal antibody was generated for a macrophage-specific surface antigen, however F4/80 staining is also observed in other hematopoietic cell populations, thus other immune cell markers should be used in conjunction with F4/80 to distinguish between different populations (1). Though the full extent of F4/80 ligands and biological functions remains elusive, studies have suggested that F4/80 is critical for macrophage-natural killer cell interaction and cytokine release (1,2). Additionally, a study of anterior chamber-associated immune deviation (ACAID) indicated a possible role for F4/80 in the generation of regulatory T cells (1,2).

References

1. Dos Anjos Cassado A. (2017). F4/80 as a Major Macrophage Marker: The Case of the Peritoneum and Spleen. Results and Problems in Cell Differentiation. https://doi.org/10.1007/978-3-319-54090-0_7

2. Hamann, J., Hsiao, C. C., Lee, C. S., Ravichandran, K. S., & Lin, H. H. (2016). Adhesion GPCRs as Modulators of Immune Cell Function. Handbook of Experimental Pharmacology. https://doi.org/10.1007/978-3-319-41523-9_15

Alternate Names

DD7A5-7, Gpf480, Ly71

Gene Symbol

EMR1

Additional F4/80 Products

Product Documents for F4/80 Antibody (4J7L6)

Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Product Specific Notices for F4/80 Antibody (4J7L6)

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
