HSP90 beta Antibody (2-1-G3-R)

Western Blot: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446]

Western Blot: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446] - Western blot analysis of HSP90 beta on different lysates with Mouse anti-HSP90 beta antibody (NBP3-32446) at 1/1,000 dilution.

Lane 1: HeLa cell lysate (20 ug/Lane)
Lane 2: HepG2 cell lysate (20 ug/Lane)
Lane 3: A549 cell lysate (20 ug/Lane)
Lane 4: K-562 cell lysate (20 ug/Lane)
Lane 5: Jurkat cell lysate (20 ug/Lane)
Lane 6: NIH/3T3 cell lysate (20 ug/Lane)
Lane 7: C6 cell lysate (20 ug/Lane)
Lane 8: PC-12 cell lysate (20 ug/Lane)
Lane 9: Mouse brain tissue lysate (40 ug/Lane)
Lane 10: Mouse heart tissue lysate (40 ug/Lane)
Lane 11: Rat brain tissue lysate (40 ug/Lane)

Predicted band size: 83 kDa
Observed band size: 83 kDa

Exposure time: 53 seconds;

4-20% SDS-PAGE gel.

Proteins were transferred to a PVDF membrane and blocked with 5% NFDM/TBST for 1 hour at room temperature. The primary antibody (NBP3-32446) at 1/1,000 dilution was used in 5% NFDM/TBST at room temperature for 2 hours. Goat Anti-Mouse IgG - HRP Secondary Antibody at 1/100,000 dilution was used for 1 hour at room temperature.

Immunohistochemistry: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446]

Immunohistochemistry: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446] - Immunohistochemical analysis of paraffin-embedded human brain tissue with Mouse anti-HSP90 beta antibody (NBP3-32446) at 1/5,000 dilution.

The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 9.0) for 20 minutes. The tissues were blocked in 1% BSA for 20 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody (NBP3-32446) at 1/5,000 dilution for 1 hour at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.

Immunocytochemistry/ Immunofluorescence: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446]

Immunocytochemistry/ Immunofluorescence: HSP90 beta Antibody (2-1-G3-R) [NBP3-32446] - Immunocytochemistry analysis of HeLa cells labeling HSP90 beta with Mouse anti-HSP90 beta antibody (NBP3-32446) at 1/100 dilution.

Cells were fixed in 100% precooled methanol for 5 minutes at room temperature, then blocked with 1% BSA in 10% negative goat serum for 1 hour at room temperature. Cells were then incubated with Mouse anti-HSP90 beta antibody (NBP3-32446) at 1/100 dilution in 1% BSA in PBST overnight at 4 ℃. Goat Anti-Mouse IgG H&L (iFluor™ 488) was used as the secondary antibody at 1/1,000 dilution. PBS instead of the primary antibody was used as the secondary antibody only control. Nuclear DNA was labelled in blue with DAPI.

beta Tubulin (red) was stained at 1/100 dilution overnight at +4℃. Goat Anti-Rabbit IgG H&L (iFluor™ 594) were used as the secondary antibody at 1/1,000 dilution.
