Key Product Details

Species Reactivity

Validated:

Human

Cited:

Human, Mouse

Applications

Validated:

CyTOF-reported, Flow Cytometry, Neutralization

Cited:

Binding Assay, Bioassay, Flow Cytometry, Immunocytochemistry, Immunohistochemistry, Immunohistochemistry-Frozen, Immunohistochemistry-Paraffin, Neutralization, Neutralization Control, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2A Clone # 12G5

Product Specifications

Immunogen

CP-MAC-infected SUP-T1 human T cell lymphoblastic lymphoma line
Accession # P61073

Specificity

Detects human CXCR4.

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2A

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.

Scientific Data Images for Human CXCR4 Antibody

Detection of CXCR4 antibody in Human Blood Lymphocytes antibody by Flow Cytometry.

Detection of CXCR4 in Human Blood Lymphocytes by Flow Cytometry.

Human peripheral blood lymphocytes were stained with Mouse Anti-Human CD19 APC-conjugated Monoclonal Antibody (Catalog # FAB4867A) and either (A) Mouse Anti-Human CXCR4 Monoclonal Antibody (Catalog # MAB170) or (B) Mouse IgG2AIsotype Control (Catalog # MAB003) followed by Phycoerythrin-conjugated Anti-Mouse IgG Secondary Antibody (Catalog # F0102B). View our protocol for Staining Membrane-associated Proteins.
Chemotaxis Induced by CXCL12/SDF-1 alpha and Neutrali-zation by Human CXCR4 Antibody.

Chemotaxis Induced by CXCL12/SDF-1 alpha and Neutrali-zation by Human CXCR4 Antibody.

Recombinant Human/ Feline/Rhesus Macaque CXCL12/SDF-1a (Catalog # 350-NS) chemoattracts the BaF3 mouse pro-B cell line transfected with human CXCR4 in a dose-dependent manner (orange line). The amount of cells that migrated through to the lower chemotaxis chamber was measured by Resazurin (Catalog # AR002). Chemotaxis elicited by Recombinant Human/Feline/ Rhesus Macaque CXCL12/ SDF-1a (1 ng/mL) is neutralized (green line) by increasing concentrations of Human CXCR4 Monoclonal Antibody (Catalog # MAB170). The ND50 is typically 0.3-1.2 µg/mL.

Detection of CXCR4 in Jurkat cells vs K562 by Flow Cytometry

Jurkat (filled histogram) vs K562 (open histogram) cells were stained with Mouse Anti-Human CXCR4 Monoclonal Antibody followed by Phycoerythrin-conjugated Anti-Mouse IgM Secondary Antibody (Catalog # F0116). View our protocol for Staining Membrane-associated Proteins.

Applications for Human CXCR4 Antibody

Application
Recommended Usage

CyTOF-reported

Nair, N. et al. (2016) Mucosal Immunol. 9: 68. Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.

Flow Cytometry

0.25 µg/106 cells
Sample: see below

Neutralization

Measured by its ability to neutralize CXCL12/SDF-1 alpha-induced chemotaxis in the BaF3 mouse pro-B cell line transfected with human CXCR4. The Neutralization Dose (ND50) is typically 0.3-1.2 µg/mL in the presence of 1 ng/mL Recombinant Human/Feline/Rhesus Macaque CXCL12/SDF-1 alpha.
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Formulation, Preparation, and Storage

Purification

Protein A or G purified from ascites

Reconstitution

Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. See Certificate of Analysis for details.
*Small pack size (-SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: CXCR4

CXCR4, also known as CD184, is a G-protein-linked seven transmembrane spanning receptor that binds stromal cell-derived factor-1 (SDF-1). CXCR4 acts as a co-factor for T-cell tropic HIV-1 and -2 viral entry into cells. While primarily a membrane protein, CXCR4 undergoes trafficking and internalization in response to stimulation with phorbol esters and ligand (1). Cytoplasmic and nuclear localization of CXCR4 has been observed in colorectal and renal carcinomas (2,3) and it has been used as the basis of prognosis and metastatic state (3,4,5).

References

  1. Orsini, M.J. et al. (1999) J. Biol. Chem. 274:31076.
  2. Zagzag, D. et al. (2005) Cancer Res. 65:6178.
  3. Speetjens, F.M. et al. (2009) Cancer Microenvironment 2:1.
  4. Wang, L. et al. (2009) Oncology Reports 22:1333.
  5. Amara, S. et al. (2015) Cancer Biomark. 15:869.

Long Name

C-X-C Motif Chemokine Receptor 4

Alternate Names

CD184, D2S201E, FB22, Fusin, HM89, HSY3RR, LAP-3, LAP3, LCR1, LESTR, NPY3R, NPYRL, NPYY3R, WHIMS

Entrez Gene IDs

7852 (Human); 12767 (Mouse); 60628 (Rat); 483900 (Canine); 493676 (Feline)

Gene Symbol

CXCR4

UniProt

Additional CXCR4 Products

Product Documents for Human CXCR4 Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Human CXCR4 Antibody

For research use only
