Human/Mouse Plexin A1 Antibody

R&D Systems, part of Bio-Techne | Catalog # AF4309

R&D Systems, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
Loading...
AF4309
AF4309-SP

Key Product Details

Species Reactivity

Validated:

Human, Mouse

Cited:

Human, Mouse

Applications

Validated:

Immunocytochemistry, Immunohistochemistry, Western Blot

Cited:

Immunocytochemistry, Immunohistochemistry, Neutralization, Western Blot

Label

Unconjugated

Antibody Source

Polyclonal Goat IgG

Product Specifications

Immunogen

Mouse myeloma cell line NS0-derived recombinant mouse Plexin A1
Ser28-Pro1242
Accession # P70206

Specificity

Detects mouse Plexin A1 in direct ELISAs and Western blots. In direct ELISAs, less than 5% cross-reactivity with recombinant mouse Plexin A2 is observed.

Clonality

Polyclonal

Host

Goat

Isotype

IgG

Scientific Data Images for Human/Mouse Plexin A1 Antibody

Detection of Mouse Plexin A1 antibody by Western Blot.

Detection of Mouse Plexin A1 by Western Blot.

Western blot shows lysates of mouse embryonic heart tissue. PVDF Membrane was probed with 1 µg/mL of Mouse Plexin A1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF4309) followed by HRP-conjugated Anti-Goat IgG Secondary Antibody (Catalog # HAF019). A specific band was detected for Plexin A1 at approximately 200 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 8.
Plexin A1 antibody in Human Dendritic Cells by Immunocytochemistry (ICC).

Plexin A1 in Human Dendritic Cells.

Plexin A1 was detected in immersion fixed immature human dendritic cells using Goat Anti-Mouse Plexin A1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF4309) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counterstained with DAPI (blue). Specific staining was localized to cell surfaces and cytoplasm. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.
Plexin A1 antibody in Mouse Spinal Cord by Immunohistochemistry (IHC-Fr).

Plexin A1 in Mouse Spinal Cord.

Plexin A1 was detected in immersion fixed frozen sections of embryonic mouse spinal cord using Mouse Plexin A1 Affinity-purified Polyclonal Antibody (Catalog # AF4309) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.

Applications for Human/Mouse Plexin A1 Antibody

Application
Recommended Usage

Immunocytochemistry

5-15 µg/mL
Sample: Immersion fixed immature human dendritic cells

Immunohistochemistry

5-15 µg/mL
Sample: Immersion fixed frozen sections of embryonic mouse spinal cord

Western Blot

1 µg/mL
Sample: Mouse embryonic heart tissue
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Sterile PBS to a final concentration of 0.2 mg/mL. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: Plexin A1

Plexin A1 (formerly Plexin 1) is a 200 kDa type I transmembrane protein that is a member of the Plexin family of Semaphorin signal transducers (1). Plexin signaling induces cytoskeletal remodeling, which mediates cell migration and axon repulsion (2). The mouse Plexin A1 cDNA encodes 1894 amino acids (aa) including a 27 aa signal sequence, a 1215 aa extracellular domain (ECD) with one Sema domain, a spacer, and four tandem IPT/TIG domains, a 21 aa transmembrane segment, and a 631 aa cytoplasmic domain (1). Within the ECD, human Plexin A1 shares 95%, 95%, 92%, 80% and 79% aa sequence identity with mouse, rat, bovine, chicken and Xenopus Plexin A1, respectively. The four mouse Plexin A molecules share 59‑67% aa identity with each other. Plexin A1 binds Class 3 (secreted) Semaphorins indirectly via Neuropilin (Npn)-1 and Npn-2, and binds transmembrane Semaphorin 6D directly (3‑5). Sema3A engagement of Plexin A1 and Npn-1 guides proprioceptive and sensory neurons during development, while Sema3B engagement guides floorplate neurons (5‑8). In contrast, T cell Sema6D engagement of dendritic cell Plexin A1 controls actin polymeration, which supports formation of immunological synapses and enhances the function of the dendritic cells (3, 4, 9). Complex formation with DAP12 allows Plexin A1 signaling through TREM family proteins (10, 11). However, the most striking effect of Plexin A1 deletion is on bone homeostasis, where Plexin A1-deficient mice show increased trabecular bone mass due to downregulated osteoclast differentiation (10). Plexin A1 and Sema6D are frequently expressed in malignant pleural mesothelioma, where they promote anchorage-independent growth through complexing with and activating VEGF R2 (12).

References

  1. Kameyama, T. et al. (1996) Biochem. Biophys. Res. Commun. 226:524.
  2. Kruger, R.P. et al. (2005) Nat. Rev. Mol. Cell Biol. 6:789.
  3. Takamatsu, H. et al. (2010) Cell. Mol. Immunol. 7:83.
  4. O’Connor, B.P. and J.P.Y. Ting (2008) Immunol. Res. 41:217.
  5. Takahashi, T. et al. (1999) Cell 99:59.
  6. Yoshida, Y. et al. (2006) Neuron 52:775.
  7. Toyofuku, T. et al. (2005) Nat. Neurosci. 8:1712.
  8. Nawabi, H. et al. (2010) Genes Dev. 24:396.
  9. Eun, S-Y. et al. (2006) J. Immunol. 177:4271.
  10. Takegahara, N. et al. (2006) Nat. Cell Biol. 8:615.
  11. Watarai, H. et al. (2008) Proc. Natl. Acad. Sci. USA 105:2993.
  12. Catalano, A. et al. (2009) Cancer Res. 69:1485.

Alternate Names

NOVP, PLXN1, PLXNA1

Entrez Gene IDs

5361 (Human); 18844 (Mouse)

Gene Symbol

PLXNA1
