Human/Mouse Plexin A2 Antibody

R&D Systems, part of Bio-Techne | Catalog # MAB5486

R&D Systems, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
Loading...
MAB5486
MAB5486-SP

Key Product Details

Species Reactivity

Validated:

Human, Mouse

Cited:

Human

Applications

Validated:

Immunocytochemistry, Western Blot

Cited:

Immunohistochemistry

Label

Unconjugated

Antibody Source

Monoclonal Rat IgG2B Clone # 583603

Product Specifications

Immunogen

Chinese hamster ovary cell line CHO-derived recombinant mouse Plexin A2
Met35-Pro1237
Accession # P70207

Specificity

Detects mouse Plexin A2 in direct ELISAs and Western blots. In direct ELISAs, no cross-reactivity with recombinant human Plexin A4, B1, B2, D1, recombinant mouse Plexin A1, A3, B3, or C1 is observed.

Clonality

Monoclonal

Host

Rat

Isotype

IgG2B

Scientific Data Images for Human/Mouse Plexin A2 Antibody

Detection of Mouse Plexin A2 antibody by Western Blot.

Detection of Mouse Plexin A2 by Western Blot.

Western blot shows lysates of mouse brain tissue. PVDF Membrane was probed with 2 µg/mL of Rat Anti-Mouse Plexin A2 Monoclonal Antibody (Catalog # MAB5486) followed by HRP-conjugated Anti-Rat IgG Secondary Antibody (Catalog # HAF005). A specific band was detected for Plexin A2 at approximately 200 kDa (as indicated). This experiment was conducted under non-reducing conditions and using Immunoblot Buffer Group 1.
Plexin A2 antibody in bEnd by Immunocytochemistry (ICC).3 Mouse Cell Line by Immunocytochemistry (ICC).

Plexin A2 in bEnd.3 Mouse Cell Line.

Plexin A2 was detected in immersion fixed bEnd.3 mouse endothelioma cell line using Rat Anti-Mouse Plexin A2 Monoclonal Antibody (Catalog # MAB5486) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Rat IgG Secondary Antibody (red; Catalog # NL013) and counterstained with DAPI (blue). Specific staining was localized to cell surfaces and cytoplasm. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.
Plexin A2 antibody in HUVEC Human Cells by Immunocytochemistry (ICC).

Plexin A2 in HUVEC Human Cells.

Plexin A2 was detected in immersion fixed HUVEC human umbilical vein endothelial cells using Rat Anti-Mouse Plexin A2 Monoclonal Antibody (Catalog # MAB5486) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the Northern-Lights™ 557-conjugated Anti-Rat IgG Secondary Antibody (red; Catalog # NL013) and counterstained with DAPI (blue). Specific staining was localized to cell surfaces and cytoplasm. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.

Applications for Human/Mouse Plexin A2 Antibody

Application
Recommended Usage

Immunocytochemistry

8-25 µg/mL
Sample: Immersion fixed bEnd.3 mouse endothelioma cell line and HUVEC human umbilical vein endothelial cells

Western Blot

2 µg/mL
Sample: Mouse brain tissue under non-reducing conditions only

Formulation, Preparation, and Storage

Purification

Protein A or G purified from hybridoma culture supernatant

Reconstitution

Reconstitute at 0.5 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: Plexin A2

Plexin A2 (also OCT) is a 220-230 kDa member of the plexin-A subfamily, plexin family of proteins. It is found on cerebellar granule cells, sensory neurons, and cardiac neural crest cells. It participates in cell migration and axon guidance, and does so by serving as a receptor for Sema6A and B, and as a coreceptor with neuropilin-1 for Sema3A and C. Mature mouse Plexin A2 is an 1860 amino acid (aa) type I transmembrane glycoprotein. It contains a 1203 aa extracellular domain (ECD) and a 636 aa cytoplasmic region. The ECD contains one Sema domain (aa 35-508), three PSI domains (aa 510-855) and four IPT regions (aa 858-1228). There is one alternate start site 10 aa upstream of the standard start site. Over aa 35-1237, mouse Plexin A2 shares 96% aa sequence identity with human Plexin A2.

Alternate Names

OCT, PLXN2, PLXNA2

Entrez Gene IDs

5362 (Human); 18845 (Mouse); 289392 (Rat)

Gene Symbol

PLXNA2

UniProt

Additional Plexin A2 Products

Product Documents for Human/Mouse Plexin A2 Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Human/Mouse Plexin A2 Antibody

For research use only
