Mouse JAM-C Antibody

R&D Systems, part of Bio-Techne | Catalog # AF1213

R&D Systems, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
Loading...
AF1213
AF1213-SP

Key Product Details

Species Reactivity

Validated:

Mouse

Cited:

Human, Mouse

Applications

Validated:

Blockade of Receptor-ligand Interaction, Immunocytochemistry, Immunohistochemistry, Western Blot

Cited:

Flow Cytometry, Immunocytochemistry, Immunohistochemistry, Immunohistochemistry-Frozen, Immunoprecipitation, Neutralization, Western Blot

Label

Unconjugated

Antibody Source

Polyclonal Goat IgG

Product Specifications

Immunogen

Mouse myeloma cell line NS0-derived recombinant mouse JAM-C
Val32-Asn241
Accession # Q9D8B7

Specificity

Detects mouse JAM-C in direct ELISAs and Western blots. In Western blots, approximately 5% cross-reactivity with recombinant human JAM‑C and less than 2% cross-reactivity with recombinant mouse (rm) JAM-A and rmJAM-B is observed.

Clonality

Polyclonal

Host

Goat

Isotype

IgG

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.

Scientific Data Images for Mouse JAM-C Antibody

JAM-C antibody in Mouse Embryo by Immunohistochemistry (IHC-Fr).

JAM-C in Mouse Embryo.

JAM-C was detected in immersion fixed frozen sections of mouse embryo (15 d.p.c.) using Goat Anti-Mouse JAM-C Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1213) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). Specific staining was localized to muscle cells. View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.
JAM-C antibody in Mouse Splenocytes by Immunocytochemistry (ICC).

JAM‑C in Mouse Splenocytes.

JAM-C was detected in immersion fixed mouse splenocytes using Goat Anti-Mouse JAM-C Antigen Affinity-purified Polyclonal Antibody (Catalog # AF1213) at 15 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Goat IgG Secondary Antibody (red; Catalog # NL001) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. View our protocol for Fluorescent ICC Staining of Non-adherent Cells.

Applications for Mouse JAM-C Antibody

Application
Recommended Usage

Blockade of Receptor-ligand Interaction

In a functional ELISA, 3-15 µg/mL of this antibody will block 50% of the binding of 10 ng/mL of biotinylated Recombinant Mouse VEJAM to immobilized Recombinant Mouse JAM-C (Catalog # 1213-J3) coated at 2 µg/mL (100 µL/well). At 30 μg/mL, this antibody will block >90% of the binding.

Immunocytochemistry

5-15 µg/mL
Sample: Immersion fixed mouse splenocytes

Immunohistochemistry

5-15 µg/mL
Sample: Immersion fixed frozen sections of mouse embryo (15 d.p.c.)

Western Blot

0.1 µg/mL
Sample: Recombinant Mouse JAM-C Fc Chimera (Catalog # 1213-J3)

Reviewed Applications

Read 2 reviews rated 4 using AF1213 in the following applications:

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: JAM-C

The family of junctional adhesion molecules (JAM), comprised of at least three members, are type I transmembrane receptors belonging to the immunoglobulin (Ig) superfamily (1, 2). These proteins are localized in the tight junctions between endothelial cells or epithelial cells. Some family members are also found on blood leukocytes and platelets. Mouse JAM-C cDNA predicts a 310 amino acid (aa) residue  precursor protein with a putative 31 aa signal peptide, a 210 aa extracellular region containing two Ig domains, an 18 aa transmembrane domain and a 51 aa cytoplasmic domain containing a PDZ-binding motif and a PKC phosphorylation site (3). Mouse JAM-C shares 86% aa sequence identity with its human homologue. It also shares approximately 31% and 35% aa sequence homology with mouse JAM-A and JAM-B, respectively (2). Mouse JAM-C is highly expressed during embryogenesis. In adult tissues, mouse JAM-C is restricted to endothelial cells, lymph endothelial cells in the kidney, lymph node and Peyer’s patches where the protein can be localized to the high endothelial venules (3). Although human JAM-C is expressed on human platelets and a subset of leukocytes, mouse JAM-C expression was not detected on any mouse lymphocytes (4). In contrast to human JAM-C which show weak homotypic interactions, mouse JAM-C was reported to exhibit homotypic interactions (3). Mouse JAM-C has also been shown to have heterotypic interaction with JAM-B. It is likely that mouse JAM-C may play a role in lymphocyte transendothelial migration (4).

The nomenclature used for the JAM family proteins is confusing. VE-JAM has been referred to in the literature variously as JAM-B or JAM-C. Until further clarification, R&D Systems has adopted the nomenclature where both mouse and human VE-JAM are referred to as JAM-B.

References

  1. Chavakis, T. et al. (2003) Thromb. Haemost. 89:13.
  2. Aurrand-Lions, M. et al. (2001) Blood 98:3699.
  3. Aurrand-Lions, M. et al. (2001) J. Biol. Chem. 276:2733.
  4. Johnson-Leger, C. et al. (2002) Blood 100:25793.

Long Name

Junctional Adhesion Molecule C

Alternate Names

CD323, JAM3, JAMC

Entrez Gene IDs

83700 (Human); 83964 (Mouse)

Gene Symbol

JAM3

UniProt

Additional JAM-C Products

Product Documents for Mouse JAM-C Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Mouse JAM-C Antibody

For research use only
