SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Novus Biologicals, part of Bio-Techne | Catalog # NBP2-36573

Novus Biologicals, part of Bio-Techne

Key Product Details

Validated by

Biological Validation

Species Reactivity

Validated:

Human, Mouse

Cited:

Human, Mouse

Predicted:

Porcine (96%), Primate (100%), Rat (96%). Backed by our 100% Guarantee.

Applications

Validated:

Immunocytochemistry/ Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot

Cited:

Immunohistochemistry-Paraffin, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG2b Kappa Clone # 5E6.1B4

Format

BSA Free

Concentration

1.0 mg/ml

View all SLC31A1 Antibodies »

Product Specifications

Immunogen

Two synthetic peptides made to internal sequences of human SLC31A1/CTR1 protein (sequences found between amino acids 50-150) [UniProt# O15431]

Reactivity Notes

Use in Mouse reported in scientific literature (PMID:32060280).

Clonality

Monoclonal

Host

Mouse

Isotype

IgG2b Kappa

Scientific Data Images for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4)BSA Free [NBP2-36573]

Western Blot: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - Analysis of SLC31A1/CTR1 in MCF7 and HeLa at 2 ug/ml.
Immunocytochemistry/ Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunocytochemistry/ Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunocytochemistry/Immunofluorescence: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - HepG2 cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X TBS + 0.5% Triton X-100. The cells were incubated with anti SLC31A1/CTR1 (5E6.1B4) NBP2-36573 at a 1:50 dilution overnight at 4C and detected with an anti-mouse DyLight 488 (Green) at a 1:500 dilution. Actin was detected with Phalloidin 568 (Red) at a 1:200 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.
Immunohistochemistry: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573]

Immunohistochemistry: SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free [NBP2-36573] - IL-17 induces cellular copper uptake through induction of STEAP4. Western blots analysis for copper trafficking-associated proteins from lysates of mouse colon epithelial organoids treated with different inflammatory cytokines for 8h. Three independent experiments were done and representative blots were shown. Untr untreated. IL-17 primed or unprimed mouse colon organoids were stained for STEAP4 (St4), E-cadherin (E-cad) and SLC31A1/CTR1 and integrin alpha. Scale bar, 100 um. Image collected and cropped by CiteAb from the following publication (https://www.nature.com/articles/s41467-020-14698-y), licensed under a CC-BY license.
View 5 more images

Applications for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Application
Recommended Usage

Immunocytochemistry/ Immunofluorescence

1:50

Immunohistochemistry

5 ug/ml

Immunohistochemistry-Paraffin

5 ug/ml

Western Blot

2 ug/ml
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Formulation, Preparation, and Storage

Purification

Protein G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: SLC31A1

SLC31A1/CTR1 (solute carrier family 31 member 1/copper transporter 1) is a homotrimeric high-affinity, saturable copper importer implicated in dietary copper uptake. Homeostasis of copper is tightly controlled by inter-regulatory circuitry containing copper, Sp1, and CTR1, wherein Sp1 transcription factor acts as a copper sensor in modulating CTR1 expression which in turn controls cellular copper and Sp1 levels in a 3-way mutual regulatory loop. CTR1 mediated copper uptake is time, temperature, and pH dependent and specific for reduced form of Cu (I) and copper reduction has been proposed to be caused by Steap protein family or Dcytb protein (Cybrd1) both of which are reported to possess cupric reductase activity. The intracellular localization of CTR1 is variable in different cell lines: CTR1 is localized at the plasma membrane in HEK293, CaCo-2, and A2780 cells, whereas, in other cells such as HeLa, it is predominantly localized to vesicular compartments, and variability in trafficking rates between vesicular and plasma membrane compartments has been suggested as the cause of this differential localization. Post-translational O-linked glycosylation of CTR1 protects it against proteolytic cleavage of N terminal 17-kD fragment and the biological function of this cleaved variant or protease responsible is largely unknown. Selective knockout of Ctr1 in murine intestinal epithelial cells results in severe systemic copper deficiency, ataxia, and death prior to weaning.

Long Name

Solute Carrier Family 31 Member 1

Alternate Names

COPT1, CTR1, HCTR1

Entrez Gene IDs

1317 (Human)

Gene Symbol

SLC31A1

UniProt

O15431 (Human)

Additional SLC31A1 Products

Product Documents for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Download SDS

Product Specific Notices for SLC31A1/CTR1 Antibody (5E6.1B4) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
