Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free

Novus Biologicals, part of Bio-Techne | Catalog # NBP1-51691

Novus Biologicals, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
NBP1-51691
NBP1-51691SS
Print Quote
Bulk Order
100% Guarantee

Key Product Details

Species Reactivity

Validated:

Human, Mouse

Cited:

Human, Mouse

Applications

Validated:

CyTOF-ready, ELISA, Flow (Intracellular), Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot

Cited:

IF/IHC, Immunocytochemistry/ Immunofluorescence, Immunohistochemistry-Frozen, Western Blot

Label

Unconjugated

Antibody Source

Monoclonal Mouse IgG1 Clone # 2D3

Format

BSA Free

Concentration

1.0 mg/ml

View all Carbonic Anhydrase IX/CA9 Antibodies »

Product Specifications

Immunogen

This Carbonic Anhydrase IX/CA9 Antibody (2D3) was made to a purified recombinant fragment of human Carbonic Anhydrase IX expressed in E. coli [UniProt# Q16790].

Reactivity Notes

Mouse reactivity reported in scientific literature (PMID: 33153038).

Marker

Hypoxia Marker

Clonality

Monoclonal

Host

Mouse

Isotype

IgG1

Theoretical MW

50 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.

Scientific Data Images for Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free

Western Blot: Carbonic Anhydrase IX/CA9 Antibody (2D3)BSA Free [NBP1-51691]

Western Blot: Carbonic Anhydrase IX/CA9 Antibody (2D3)BSA Free [NBP1-51691]

Western Blot: Carbonic Anhydrase IX/CA9 Antibody (2D3) [NBP1-51691] - Carbonic Anhydrase IX mouse antibody against Hela (1) and A549 (2) cell lysates. Bands were detected at a molecular weight of approximately 50 kDa in both cell lines.
Immunohistochemistry-Paraffin: Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free [NBP1-51691]

Immunohistochemistry-Paraffin: Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free [NBP1-51691]

Immunohistochemistry-Paraffin: Carbonic Anhydrase IX/CA9 Antibody (2D3) [NBP1-51691] - Paraffin-embedded lung tissues (left) and colonic tissues (right) using Carbonic Anhydrase IX mouse antibody with DAB staining.
Immunocytochemistry/ Immunofluorescence: Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free [NBP1-51691]

Immunocytochemistry/ Immunofluorescence: Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free [NBP1-51691]

Immunocytochemistry/Immunofluorescence: Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free [NBP1-51691] - A431 cells were fixed in 4% paraformaldehyde for 10 minutes and permeabilized in 0.05% Triton X-100 in PBS for 5 minutes. The cells were incubated with Carbonic Anhydrase IX/CA9 Antibody [2D3] (NBP1-51691) at 2ug/ml overnight at 4C and detected with an anti-mouse DyLight 488 (Green) at a 1:1000 dilution for 60 minutes. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 100X objective and digitally deconvolved.
View 3 more images

Applications for Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free

Application
Recommended Usage

ELISA

1:10000

Flow (Intracellular)

1 ug/mL

Flow Cytometry

1:200 - 1:400

Immunohistochemistry

1:10 - 1:500

Immunohistochemistry-Paraffin

1:200 - 1:1000

Western Blot

1:2000

Reviewed Applications

Read 2 reviews rated 5 using NBP1-51691 in the following applications:

Formulation, Preparation, and Storage

Purification

Protein A or G purified

Formulation

PBS

Format

BSA Free

Preservative

0.05% Sodium Azide

Concentration

1.0 mg/ml

Shipping

The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.

Stability & Storage

Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.

Background: Carbonic Anhydrase IX/CA9

Carbonic anhydrase alpha, isozyme IX, belongs to a family of zinc-containing metalloproteins which hydrate carbon dioxide to generate bicarbonate ions and protons (1). This main catalytic function allows carbonic anhydrase IX to participate in cellular pH regulation. The large family of carbonic anhydrase metalloproteins includes three major classes which have been identified based on sequence and structure analysis. The alpha class is a monomer found in mammals. The beta class may occur as a dimer, tetramer, hexamer or octamer and is found in plants, algae, and bacteria. Lastly, the gamma class is a trimer found in bacteria and represents the most ancient carbonic anhydrase. These three classes of carbonic anhydrase enzymes lack sequence or structural similarities, but all share a conserved active site zinc atom (1).

Carbonic anhydrase IX (theoretical molecular weight 50kDa) belongs to the monomeric alpha class and is a single pass-transmembrane protein with two extracellular domains which serve catalytic and cell adhesion functions (2, 3). By cooperating with sodium bicarbonate cotransporters (NBC), lactate and proton exporting monocarboxylic acid transporters (MCT), and a sodium/hydrogen exchanger (NHE), carbonic anhydrase IX is involved in pH regulation across the cell membrane. This functional property protects cancer cells from intracellular acidification and partly explains the role of carbonic anhydrase IX in cancer cell survival and proliferation. In contrast, the pH regulating activity of carbonic anhydrase IX induces extracellular acidification, which has been implicated in epithelial to mesenchymal transition (EMT) and promoting cancer invasion. Carbonic anhydrase IX is frequently overexpressed in cancer cells (e.g., colorectal-, breast-, lung-carcinoma and brain tumors), an effect promoted by hypoxia within the tumor microenvironment (4). An exception are tumors carrying pVHL inactivating mutations, such as clear cell renal cell carcinoma (ccRCC), where HIF-alpha is stabilized due to dysfunctional proteasomal targeting and can induce HRE (Hypoxia Response Element) containing genes even under physiological normoxia (5). Carbonic anhydrase IX may be detected by immunostaining in tumors, which is found in association with necrotic tissue and metastatic cells. Because the expression of carbonic anhydrase IX correlates with both tumor grade and stage, analysis of its expression in tumors serves as a prognostic factor (4, 6).

References

1. Tripp, B. C., Smith, K., & Ferry, J. G. (2001). Carbonic Anhydrase: New Insights for an Ancient Enzyme. Journal of Biological Chemistry. https://doi.org/10.1074/jbc.R100045200

2. Nishimori, I., & Onishi, S. (2001). Carbonic anhydrase isozymes in the human pancreas. Digestive and Liver Disease. https://doi.org/10.1016/s1590-8658(01)80138-9

3. Zavadova, Z., & Zavada, J. (2005). Carbonic anhydrase IX (CA IX) mediates tumor cell interactions with microenvironment. Oncology Reports. https://doi.org/10.3892/or.13.5.977

4. Pastorekova, S., & Gillies, R. J. (2019). The role of carbonic anhydrase IX in cancer development: links to hypoxia, acidosis, and beyond. Cancer and Metastasis Reviews. https://doi.org/10.1007/s10555-019-09799-0

5. Haase, V. (2009). The VHL Tumor Suppressor: Master Regulator of HIF. Current Pharmaceutical Design. https://doi.org/10.2174/138161209789649394

6. Young, J. R., Coy, H., Kim, H. J., Douek, M., Sisk, A., Pantuck, A. J., & Raman, S. S. (2018). Association of the gross appearance of intratumoral vascularity at MDCT with the carbonic anhydrase IX score in clear cell renal cell carcinoma. American Journal of Roentgenology. https://doi.org/10.2214/AJR.18.19725

Alternate Names

CA9, G250, MN, RCC

Entrez Gene IDs

768 (Human)

Gene Symbol

CA9

UniProt

Q16790

Additional Carbonic Anhydrase IX/CA9 Products

Product Documents for Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free

Product Datasheets

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Download SDS

Product Specific Notices for Carbonic Anhydrase IX/CA9 Antibody (2D3) - BSA Free

This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
