Human/Mouse Draxin Antibody
R&D Systems, part of Bio-Techne | Catalog # AF6148
Key Product Details
Species Reactivity
Human, Mouse
Applications
Immunocytochemistry, Immunohistochemistry, Western Blot
Label
Unconjugated
Antibody Source
Polyclonal Sheep IgG
Product Specifications
Immunogen
Mouse myeloma cell line NS0-derived recombinant human Draxin
aa 26-349
Accession # Q8NBI3
aa 26-349
Accession # Q8NBI3
Specificity
Detects human Draxin in direct ELISAs and Western blots. In direct ELISAs, approximately 20% cross-reactivity with recombinant mouse Draxin is observed.
Clonality
Polyclonal
Host
Sheep
Isotype
IgG
Scientific Data Images for Human/Mouse Draxin Antibody
Detection of Human Draxin by Western Blot.
Western blot shows lysates of SH-SY5Y human neuroblastoma cell line. PVDF Membrane was probed with 1 µg/mL of Sheep Anti-Human Draxin Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6148) followed by HRP-conjugated Anti-Sheep IgG Secondary Antibody (Catalog # HAF016). A specific band was detected for Draxin at approximately 58 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.
Draxin in SH‑SY5Y Human Cell Line.
Draxin was detected in immersion fixed SH-SY5Y human neuroblastoma cell line using Sheep Anti-Human Draxin Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6148) at 10 µg/mL for 3 hours at room temperature. Cells were stained using the NorthernLights™ 557-conjugated Anti-Sheep IgG Secondary Antibody (red; Catalog # NL010) and counterstained with DAPI (blue). Specific staining was localized to cytoplasm. View our protocol for Fluorescent ICC Staining of Cells on Coverslips.
Draxin in Mouse Embryo.
Draxin was detected in immersion fixed frozen sections of mouse embryo (E13.5) using Sheep Anti-Human Draxin Antigen Affinity-purified Polyclonal Antibody (Catalog # AF6148) at 15 µg/mL overnight at 4 °C. Tissue was stained using the Anti-Sheep HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS019) and counter-stained with hematoxylin (blue). Specific staining was localized to diencephalon. View our protocol for Chromogenic IHC Staining of Frozen Tissue Sections.Applications for Human/Mouse Draxin Antibody
Application
Recommended Usage
Immunocytochemistry
5-15 µg/mL
Sample: Immersion fixed SH‑SY5Y human neuroblastoma cell line
Sample: Immersion fixed SH‑SY5Y human neuroblastoma cell line
Immunohistochemistry
5-15 µg/mL
Sample: Immersion fixed frozen sections of mouse embryo (E13.5)
Sample: Immersion fixed frozen sections of mouse embryo (E13.5)
Western Blot
1 µg/mL
Sample: SH‑SY5Y human neuroblastoma cell line
Sample: SH‑SY5Y human neuroblastoma cell line
Reviewed Applications
Read 1 review rated 4 using AF6148 in the following applications:
Formulation, Preparation, and Storage
Purification
Antigen Affinity-purified
Reconstitution
Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.
Formulation
Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.
Shipping
Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.
Stability & Storage
Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
- 12 months from date of receipt, -20 to -70 °C as supplied.
- 1 month, 2 to 8 °C under sterile conditions after reconstitution.
- 6 months, -20 to -70 °C under sterile conditions after reconstitution.
Background: Draxin
Draxin (Dorsal repulsive axon guidance protein; also neucrin) is a secreted, 58 kDa, presumable glycoprotein member of the draxin family of molecules. In mammals, it is expressed in neurons (axons), astroglia, and likely cells of the developing somite. Draxin acts as a Wnt antagonist, apparently by binding to LRP6. The net effect is to block neural crest migration, and the organization of axons into functional tracts or bundles (fasciculation). Mature human Draxin is 324 amino acids (aa) in length. It contains one potential N-linked glycosylation site, followed by a Cys-rich domain (aa 274-333). Mature human Draxin (aa 26-349) shares 79% aa identity with mature mouse Draxin.
Long Name
Dorsal Repulsive Axon Guidance Protein
Alternate Names
C1orf187, Neucrin
Gene Symbol
DRAXIN
UniProt
