Human Plexin D1 Antibody

R&D Systems, part of Bio-Techne | Catalog # AF4160

R&D Systems, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
Loading...
AF4160
AF4160-SP

Key Product Details

Species Reactivity

Validated:

Human

Cited:

Human, Mouse, Rat, Primate - Chlorocebus aethiops (African Green Monkey), Transgenic Mouse

Applications

Validated:

CyTOF-ready, Flow Cytometry, Immunohistochemistry, Neutralization, Western Blot

Cited:

Flow Cytometry, Immunocytochemistry, Immunohistochemistry, Immunohistochemistry-Paraffin, Western Blot

Label

Unconjugated

Antibody Source

Polyclonal Goat IgG

Product Specifications

Immunogen

Mouse myeloma cell line NS0-derived recombinant human Plexin D1
Leu47-Ala1271
Accession # Q9Y4D7

Specificity

Detects human Plexin D1 in direct ELISAs and Western blots.

Clonality

Polyclonal

Host

Goat

Isotype

IgG

Scientific Data Images for Human Plexin D1 Antibody

Detection of Human Plexin D1 antibody by Western Blot.

Detection of Human Plexin D1 by Western Blot.

Western blot shows lysates of JAR human choriocarcinoma cell line, IMR-32 human neuroblastoma cell line, and Jurkat human acute T cell leukemia cell line. PVDF membrane was probed with 0.5 µg/mL of Goat Anti-Human Plexin D1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF4160) followed by HRP-conjugated Anti-Goat IgG Secondary Antibody (Catalog # HAF017). A specific band was detected for Plexin D1 at approximately 250 kDa (as indicated). This experiment was conducted under reducing conditions and using Immunoblot Buffer Group 1.
Detection of Plexin D1 antibody in Human peripheral blood monocytes antibody by Flow Cytometry.

Detection of Plexin D1 in Human peripheral blood monocytes by Flow Cytometry.

Human peripheral blood monocytes were stained with Goat Anti-Human Plexin D1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF4160, filled histogram) or control antibody (Catalog # AB-108-C, open histogram), followed by Phycoerythrin-conjugated Anti-Goat IgG Secondary Antibody (Catalog # F0107).
Plexin D1 antibody in Human Melanoma by Immunohistochemistry (IHC-P).

Plexin D1 in Human Melanoma.

Plexin D1 was detected in immersion fixed paraffin-embedded sections of human melanoma using Goat Anti-Human Plexin D1 Antigen Affinity-purified Polyclonal Antibody (Catalog # AF4160) at 3 µg/mL overnight at 4 °C. Before incubation with the primary antibody, tissue was subjected to heat-induced epitope retrieval using Antigen Retrieval Reagent-Basic (Catalog # CTS013). Tissue was stained using the Anti-Goat HRP-DAB Cell & Tissue Staining Kit (brown; Catalog # CTS008) and counterstained with hematoxylin (blue). Specific staining was localized to plasma membranes. View our protocol for Chromogenic IHC Staining of Paraffin-embedded Tissue Sections.

Applications for Human Plexin D1 Antibody

Application
Recommended Usage

CyTOF-ready

Ready to be labeled using established conjugation methods. No BSA or other carrier proteins that could interfere with conjugation.

Flow Cytometry

0.25 µg/106 cells
Sample: Human peripheral blood monocytes

Immunohistochemistry

3-15 µg/mL
Sample: Immersion fixed paraffin-embedded sections of human melanoma

Western Blot

0.5 µg/mL
Sample: JAR human choriocarcinoma cell line, IMR‑32 human neuroblastoma cell line, and Jurkat human acute T cell leukemia cell line

Neutralization

Measured by its ability to neutralize Semaphorin 3E-induced inhibition of the HUVEC human umbilical vein endothelial cells. Sakurai, A. et al. (2010) Mol Cell Bio 12:3086-98. The Neutralization Dose (ND50) is typically 0.5-2  ug/mL.

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: Plexin D1

Plexin D1 is a type I transmembrane glycoprotein that is the prototype of the plexin D subfamily of semaphorin receptors (1, 2). Human Plexin D1 contains a 46 amino acid (aa) signal sequence, a 1225 aa extracellular domain (ECD), a 21 aa transmembrane domain, and a 633 aa cytoplasmic domain that includes features common to other plexins (1). The human Plexin D1 ECD shares 89% identity with mouse Plexin D1, and ~84-92% aa identity based on incomplete sequences of rat, bovine, porcine and canine Plexin D1. It contains a sema domain, two plexin-semaphorin-integrin (PSI) or Met-related sequence (MRS) cysteine-rich motifs, and three glycine/proline-rich IPT/TIG domains which are immunoglobulin-like domains found in plexins, transcription factors, and the scatter factor receptors Met and Ron (1, 2). Isoforms of 1787 and 1747 aa have been sequenced; these contain a 178 aa N-terminal deletion with or without a longer alternate C-terminus (3). Like other Sema/plexin interactions, Plexin D1 interacts with Sema3C or Sema4A via neuropilins. Interaction with Sema3E, however, is direct (4). Plexin D1/Sema3E interaction mediates vascular guidance during development or angiogenesis; deletion of either molecule results in similar, profound cardiac abnormalities (4, 5). Plexin D1 is also expressed in lymphocytes, osteoblasts, the neural crest and the central nervous system during development (2, 6). In the brain, the presence of neuropilin can change Plexin D1/Sema3E interaction from an attractive to a repulsive signal (7, 8). Plexin D1 directs migration of thymocytes to the thymic medulla, probably through repulsion of Sema3E (9). Endothelial cell Plexin D1 binding to Sema4A can oppose VEGF and suppresses tumor angiogenesis, and expression of Sema3E correlates inversely with tumor metastasis, indicating that Plexin D1 is anti-metastatic in the presence of its ligands (10, 11).

References

  1. Negishi, M. et al. (2005) Cell. Mol. Life Sci. 62:1363.
  2. Van Der Zwaag, B. et al. (2002) Dev. Dyn. 225:336.
  3. Entrez protein Accession # Q9Y4D7, EAW79239, EAW79240.
  4. Gu, C. et al. (2005) Science 307:265.
  5. Gitler, A.D. et al. (2004) Developmental Cell 7:107.
  6. Zhang, Y. et al. (2009) Dev. Biol. 325:82.
  7. Chauvet, S. et al. (2007) Neuron 56:807.
  8. Pecho-Vrieseling, E. et al. (2009) Nature 459:842.
  9. Choi, Y.I. et al. (2008) Immunity 29:888.
  10. Toyofuku, T. et al. (2007) EMBO J. 26:1373.
  11. Roodink, I. et al. (2008) Am. J. Pathol. 173:1873.

Alternate Names

PLXND1

Entrez Gene IDs

23129 (Human); 67784 (Mouse)

Gene Symbol

PLXND1

UniProt
