Perilipin-2/ADFP Antibody - BSA Free

Immunohistochemical Staining of Perilipin-2/ADFP in Mouse Liver Tissue

ADFP antibody was tested in mouse liver using DAB with hematoxylin counterstain.

Immunocytochemistry/Immunofluorescence Staining of Perilipin-2/ADFP in NIH3T3 Cells

NIH3T3 cells were fixed in 4% paraformaldehyde for 10 minutes and permeabilized in 0.05% Triton X-100 in PBS for 5 minutes. The cells were incubated with anti-Perilipin-2/ADFP Antibody NB110-40877 at 1 ug/ml overnight at 4C and detected with an anti-rabbit Dylight 488 (Green) at a 1:1000 dilution for 60 minutes. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 100X objective and digitally deconvolved.

Western Blot Detection of Perilipin-2/ADFP in Mouse Liver Lysate

Detection of murine ADFP in mouse liver lysate.

Immunocytochemistry/Immunofluorescence Staining of Perilipin-2/ADFP in HepG2 Cells

HepG2 cells were fixed for 10 minutes using 10% formalin and then permeabilized for 5 minutes using 1X TBS + 0.5% Triton-X100. The cells were incubated with anti-Perilipin-2/ADFP at a 1:100 dilution overnight at 4C and detected with an anti-rabbit Dylight 488 (Green) at a 1:500 dilution. Alpha tubulin (DM1A) NB100-690 was used as a co-stain at a 1:1000 dilution and detected with an anti-mouse Dylight 550 (Red) at a 1:500 dilution. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 40X objective.

Immunocytochemistry/Immunofluorescence Analysis of Perilipin-2/ADFP in HepG2 Cells

HepG2 cells were fixed in 4% paraformaldehyde for 10 minutes and permeabilized in 0.05% Triton X-100 in PBS for 5 minutes. The cells were incubated with anti-Perilipin-2/ADFP Antibody NB110-40877 at 1 ug/ml overnight at 4C and detected with an anti-rabbit Dylight 488 (Green) at a 1:1000 dilution for 60 minutes. Nuclei were counterstained with DAPI (Blue). Cells were imaged using a 100X objective and digitally deconvolved.

Western Blot: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] -

Western Blot: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] - Western blot images (A) & quantifications (B–I) of muscle samples from WT & UCHL1 smKO mice for lipase ATGL (B), HSL (C), & MAGL (D), the fatty acid transport protein CD36 (E), the key lipid synthesis enzyme DGAT2 (F), perilipin 3 (G), perilipin 2 (H), & UCHL1 (I). n = 4-5 per group. Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/35464088), licensed under a CC-BY license. Not internally tested by Novus Biologicals.

Western Blot: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] -

Western Blot: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] - Western blot images (A) & quantifications (B–G) of cell lysates from C2C12 myotubes with control or UCHL1 siRNA knockdown for perilipin 2 (B), perilipin 5 (C), CD36 (D), HSL (E), MAGL (F), & SDHB (G). n = 4 per group. Image collected & cropped by CiteAb from the following publication (https://pubmed.ncbi.nlm.nih.gov/35464088), licensed under a CC-BY license. Not internally tested by Novus Biologicals.

Immunocytochemistry/ Immunofluorescence: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] -

Immunocytochemistry/ Immunofluorescence: Perilipin-2/ADFP Antibody - BSA Free [NB110-40877] - Lack of MT4-MMP in patrolling monocytes leads to the accumulation of Mafb+AIM+ macrophages in incipient atherosclerotic plaques. a Representative images of transverse sections of aortic sinus from Ldlr–/– mice transplanted with MT4-MMP+/+ (MT4+/+) or MT4-MMP–/– (MT4–/–) BM cells & fed a HFD for 1 week; sections were labeled for Mac3 (green), Mafb (red), & AIM (white), & with Hoechst (blue; nuclei); scale bar, 10 µm. b Number of Mac3+ cells (left), Mac3+Mafb+ cells (middle), & Mac3+Mafb+AIM+ cells (right) in the plaques of BM-transplanted Ldlr–/– mice fed a HFD for 1 week. c Representative images of transverse sections of aortic sinus from BM-transplanted Ldlr–/– mice fed a HFD for 1 week; sections were labeled for Mac3 (green), Mafb (red), & adipophilin (white), & with Hoechst (blue; nuclei); scale bar, 10 µm. d Relative % of adipophilin-positive & adipophilin-negative cells within the Mac3+Mafb+ population of BM-transplanted Ldlr–/– mice (1 week on HFD); n = 7 mice per genotype in two independent experiments. Data were tested by two-tailed Student’s t-test in b & by Fisher’s exact test in d. Results are expressed as mean ± SEM. *p < 0.05 Image collected & cropped by CiteAb from the following publication (https://www.nature.com/articles/s41467-018-03351-4), licensed under a CC-BY license. Not internally tested by Novus Biologicals.
