Rat CCL20/MIP-3 alpha Antibody

R&D Systems, part of Bio-Techne | Catalog # AF540

R&D Systems, part of Bio-Techne
Catalog #
Availability
Size / Price
Qty
Loading...
AF540
AF540-SP

Key Product Details

Species Reactivity

Validated:

Rat

Cited:

Mouse

Applications

Validated:

Neutralization, Western Blot

Cited:

Immunohistochemistry-Frozen, Western Blot

Label

Unconjugated

Antibody Source

Polyclonal Goat IgG

Product Specifications

Immunogen

E. coli-derived recombinant rat CCL20/MIP-3 alpha (R&D Systems, Catalog # 540-RM)
Ala26-Met96
Accession # P97884

Specificity

Detects rat CCL20/MIP-3 alpha in direct ELISAs and Western blots. In these formats, approximately 50% cross-reactivity with recombinant human CCL20/MIP-3 alpha is observed.

Clonality

Polyclonal

Host

Goat

Isotype

IgG

Endotoxin Level

<0.10 EU per 1 μg of the antibody by the LAL method.

Scientific Data Images for Rat CCL20/MIP-3 alpha Antibody

Chemotaxis Induced by CCL20/MIP-3 alpha and Neutralization by Rat CCL20/MIP-3 alpha Antibody.

Chemotaxis Induced by CCL20/MIP-3 alpha and Neutralization by Rat CCL20/MIP-3 alpha Antibody.

Recombinant Rat CCL20/MIP-3a (Catalog # 540-RM) chemoattracts the BaF3 mouse pro-B cell line transfected with human CCR6 in a dose-dependent manner (orange line). The amount of cells that migrated through to the lower chemotaxis chamber was measured by Resazurin (Catalog # AR002). Chemotaxis elicited by Recombinant Rat CCL20/MIP-3a (5 µg/mL) is neutralized (green line) by increasing concentrations of Rat CCL20/MIP-3a Antigen Affinity-purified Polyclonal Antibody (Catalog # AF540). The ND50 is typically 30-75 µg/mL.

Applications for Rat CCL20/MIP-3 alpha Antibody

Application
Recommended Usage

Western Blot

0.1 µg/mL
Sample: Recombinant Rat CCL20/MIP-3 alpha (Catalog # 540-RM)

Neutralization

Measured by its ability to neutralize CCL20/MIP-3 alpha-induced chemotaxis in the BaF3 mouse pro-B cell line transfected with human CCR6. The Neutralization Dose (ND50) is typically 30-75 µg/mL in the presence of 5 µg/mL Recombinant Rat CCL20/MIP-3 alpha.
Please Note: Optimal dilutions of this antibody should be experimentally determined.

Formulation, Preparation, and Storage

Purification

Antigen Affinity-purified

Reconstitution

Reconstitute at 0.2 mg/mL in sterile PBS. For liquid material, refer to CoA for concentration.

Reconstitution Buffer Available:
Size / Price
Qty
Loading...

Formulation

Lyophilized from a 0.2 μm filtered solution in PBS with Trehalose. *Small pack size (SP) is supplied either lyophilized or as a 0.2 µm filtered solution in PBS.

Shipping

Lyophilized product is shipped at ambient temperature. Liquid small pack size (-SP) is shipped with polar packs. Upon receipt, store immediately at the temperature recommended below.

Stability & Storage

Use a manual defrost freezer and avoid repeated freeze-thaw cycles.
  • 12 months from date of receipt, -20 to -70 °C as supplied.
  • 1 month, 2 to 8 °C under sterile conditions after reconstitution.
  • 6 months, -20 to -70 °C under sterile conditions after reconstitution.

Background: CCL20/MIP-3 alpha

CCL20, also known as MIP-3 alpha, LARC (Liver and Activation-regulated Chemokine) and as Exodus, is one of many novel beta chemokines identified through bioinformatics. Rat CCL20 cDNA encodes a 96 amino acid (aa) precursor protein with a 25 aa putative signal peptide that is predicted to be cleaved to form the 71 aa mature secreted protein. CCL20 is distantly related to other beta chemokines (20-28% aa sequence identity). Rat MIP-3 alpha shares approximately 70 and 61% aa sequence homology with mouse and human CCL20, respectively.

CCL20 has been shown to be expressed predominantly in lymph nodes, appendix, PBL, fetal liver, fetal lung, and epithelial cells of intestinal tissues. The expression of CCL20 is strongly up-regulated by inflammatory signals and down-regulated by the anti-inflammatory cytokine IL-10. Synthetic or recombinant CCL20 has been shown to be chemotactic for lymphocytes and dendritic cells, and inhibits proliferation of myeloid progenitors in colony formation assays. CCL20 has now been shown to be a unique functional ligand for CCR-6 (previously referred to as GPR-CY4, CKR-L3, or STRL22 orphan receptor), a chemokine receptor that is selectively and highly expressed in human dendritic cells derived from CD34+ cord blood precursors.

Alternate Names

exodus-1, LARC, MIP-3 alpha, MIP3 alpha

Entrez Gene IDs

6364 (Human); 20297 (Mouse); 29538 (Rat)

Gene Symbol

CCL20

UniProt

Additional CCL20/MIP-3 alpha Products

Product Documents for Rat CCL20/MIP-3 alpha Antibody

Certificate of Analysis

To download a Certificate of Analysis, please enter a lot number in the search box below.

Note: Certificate of Analysis not available for kit components.

Product Specific Notices for Rat CCL20/MIP-3 alpha Antibody

For research use only
