ZAP70 Antibody (A1B5)
Novus Biologicals, part of Bio-Techne | Catalog # NBP2-89121
Key Product Details
Validated by
Biological Validation
Species Reactivity
Human, Mouse, Rat
Applications
Flow Cytometry, Immunocytochemistry/ Immunofluorescence, Immunohistochemistry-Paraffin, Western Blot
Label
Unconjugated
Antibody Source
Monoclonal Mouse IgG2A Clone # A1B5
Concentration
2 mg/ml
Product Specifications
Immunogen
Recombinant protein within human ZAP70 aa 250-480. (SwissProt: P43403 Human)
Localization
Cell membrane, cytoplasm.
Clonality
Monoclonal
Host
Mouse
Isotype
IgG2A
Theoretical MW
70 kDa.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Disclaimer note: The observed molecular weight of the protein may vary from the listed predicted molecular weight due to post translational modifications, post translation cleavages, relative charges, and other experimental factors.
Scientific Data Images for ZAP70 Antibody (A1B5)
Western Blot: ZAP70 Antibody (A1B5) [NBP2-89121]
Western Blot: ZAP70 Antibody (A1B5) [NBP2-89121] - Analysis of ZAP70 on Jurkat cell lysate. Proteins were transferred to a PVDF membrane and blocked with 5% BSA in PBS for 1 hour at room temperature. The primary antibody( 1/500) was used in 5% BSA at room temperature for 2 hours. Goat Anti-Mouse IgG - HRP Secondary Antibody at 1:5,000 dilution was used for 1 hour at room temperature.Immunohistochemistry-Paraffin: ZAP70 Antibody (A1B5) [NBP2-89121]
Immunohistochemistry-Paraffin: ZAP70 Antibody (A1B5) [NBP2-89121] - Analysis of paraffin-embedded human tonsil tissue using anti-ZAP70 antibody. The section was pre-treated using heat mediated antigen retrieval with Tris-EDTA buffer (pH 8.0-8.4) for 20 minutes.The tissues were blocked in 5% BSA for 30 minutes at room temperature, washed with ddH2O and PBS, and then probed with the primary antibody( 1/50) for 30 minutes at room temperature. The detection was performed using an HRP conjugated compact polymer system. DAB was used as the chromogen. Tissues were counterstained with hematoxylin and mounted with DPX.Flow Cytometry: ZAP70 Antibody (A1B5) [NBP2-89121]
Flow Cytometry: ZAP70 Antibody (A1B5) [NBP2-89121] - Analysis of ZAP70 was done on Jurakt cells. The cells were fixed, permeabilized and stained with the primary antibody( 1/50) (red). After incubation of the primary antibody at room temperature for an hour, the cells were stained with a Alexa Fluor 488-conjugated Goat anti-Mouse IgG Secondary antibody at 1/1000 dilution for 30 minutes.Unlabelled sample was used as a control (cells without incubation with primary antibody; black).Applications for ZAP70 Antibody (A1B5)
Application
Recommended Usage
Flow Cytometry
1:50-1:100
Immunocytochemistry/ Immunofluorescence
1:50
Immunohistochemistry-Paraffin
1:50-1:100
Western Blot
1:500-1:2000
Formulation, Preparation, and Storage
Purification
Protein G purified
Formulation
PBS (pH7.4), 0.2% BSA, 50% Glycerol
Preservative
0.05% Sodium Azide
Concentration
2 mg/ml
Shipping
The product is shipped with polar packs. Upon receipt, store it immediately at the temperature recommended below.
Stability & Storage
Store at 4C short term. Aliquot and store at -20C long term. Avoid freeze-thaw cycles.
Background: ZAP70
Long Name
Zeta-chain [TCR] Associated Protein Kinase 70 kDa
Alternate Names
mrtle, mur, SRK, STD, TZK
Gene Symbol
ZAP70
Additional ZAP70 Products
Product Documents for ZAP70 Antibody (A1B5)
Product Specific Notices for ZAP70 Antibody (A1B5)
This product is for research use only and is not approved for use in humans or in clinical diagnosis. Primary Antibodies are guaranteed for 1 year from date of receipt.
